Magewell 53020 Ultra Stream SDI - Standalone Box for Recording/Streaming - 1-Channel 3G SDI with Loop-Through Out

ITEM #: MGW-53020 MFG #: 53020

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

Our Price:

$449.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    53020 - Overview

    The Magewell Ultra Stream SDI Encoder makes live streaming remarkably simple even for nonprofessional users, enabling them to record or stream high-quality video with one click using on-device buttons or an intuitive smartphone app. Designed for users who want to stream but may have minimal technical knowledge, the encoder is ideal for everyone from church volunteers and educators to corporate communicators and live event organizers.

    Users can stream to popular services including YouTube, Facebook Live or Twitch or to a custom-specified server. Streams can be output to a third-party service and custom server simultaneously, while real-time video preview in the app allows easy monitoring. In addition to outputting live streams, Ultra Stream can record video as files to a directly-connected USB drive, embedded storage or the associated smartphone.

    • Features:

      • Streaming to Facebook, Twitch and YouTube platforms
      • Support for streaming to 2 servers simultaneously
      • Recording to USB flash drive
      • Recording to mobile device
      • Remotely control recording and streaming
      • Device configuration using Web UI

    • Specifications:

      • Inputs: BNC: SD/HD/3G SDI
      • Microphone: 1 x 3.5 mm
      • Outputs HDMI: BNC: SD/HD/3G SDI
      • Headphones: 1 x 3.5 mm
      • Other I/O Storage: 1 x USB 2.0 Type-A
      • Ethernet: 1 x RJ45
      • Resolution Support Input: SD/HD/3Ga/3Gb/3Gb-DL/3Gb-DS Standard
      • Recording: Up to 1920 x 1080 at 60 fps
      • Frame Rate Support Input: 60/60i/30/25
      • Recording: 60/50/30/25/24/15
      • Sampling Input: 12/10/8-bit 4:4:4, 4:2:2, 4:2:0
      • Recording: 8-bit, 4:2:0
      • Wireless Connectivity Wi-Fi: IEEE 802.11 a/b/g/n/ac
      • Bluetooth: 4.0 BLE
      • Power Input: 1 x Coaxial, 5 VDC, 2 A
      • Power Consumption: 6 W (max)
      • Environmental: Operating Temperature: 32 to 104°F, Storage Temperature: -4 to 158°F
      • Relative Humidity: 5-90%, non-condensing
      • Dimensions: 3.7 x 3.7 x 1.1" / 94 x 94 x 29 mm
      • Package Weight: 0.9 lb
      • Box Dimensions (LxWxH): 6.9 x 4.7 x 0.86 Inches

    • Item Includes:

      • 1x Power Adapter (US)
      • 1x Power Cable
      • 1x HDMI Cable

    • Warranty:

      • 2 Year Warranty

    • GTIN:

      8143950201225
