RF Venue ILAMP-ACT Inline 10dB Wireless Microphone RF Amplifier

ITEM #: RFV-ILAMP-ACT MFG #: ILAMP-ACT

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$241.00

Our Price:

$229.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


    ILAMP-ACT - Overview

    The RF Venue ILAMP-ACT is an in-line amplifier designed to compensate for RF antenna signal loss on long coax runs.

    One ILAMP-ACT provides 10 dB of gain, enough to compensate for 66' of RG-58 cable. For longer runs, up to two in-line amps can be cascaded using either a BNC female to BNC female adapter or a coax jumper cable (both available separately).

    The unit can be powered via the antenna power output from an antenna distributor or a receiver, or using the included AC adapter. A red light indicates the unit is getting power.

    • Features:

      • Compensate for Signal Loss on Coax Runs
      • Provides 10 dB of Gain
      • BNC I/O
      • AC Adapter or Distributor/Receiver Power

    • Specifications:

      • Frequency Band: 470 to 960 MHz
      • Gain: 10 dB, Nominal
      • Operation Voltage: 12 VDC, 0.5 A
      • Power Level: -60 to -20 dBm
      • Connector 1: BNC Female
      • Connector 2: BNC Female
      • Dimensions: 3 x 0.7 x 3" / 75 x 18.2 x 77 mm
      • Weight: 4.9 oz / 140 g
      • Package Weight: 0.7 lb
      • Box Dimensions (LxWxH): 14.8 x 3.8 x 2.5"

    • GTIN:

      0718122341511
