Roland VC-1-DL Bi-directional SDI/HDMI with Delay and Frame Sync
  • Roland VC-1-DL Bi-directional SDI/HDMI with Delay and Frame Sync
  • Roland VC-1-DL Bi-directional SDI/HDMI with Delay and Frame Sync
  • Roland VC-1-DL Bi-directional SDI/HDMI with Delay and Frame Sync
  • Roland VC-1-DL Bi-directional SDI/HDMI with Delay and Frame Sync
  • Roland VC-1-DL Bi-directional SDI/HDMI with Delay and Frame Sync

Questions? Ask a Markertek Expert:
800-522-2025 Email

Roland VC-1-DL Bi-directional SDI/HDMI with Delay and Frame Sync

Manufacturer: Roland Professional AV

Item #: ROL-VC-1-DL   •   MFG #: VC-1-DL




Our Price:$795.00

free ship


Availability: Usually ships in 3-10 business days
i
This item is currently out of stock and will ship the minute we receive it – typically 3-10 business days. Need it sooner? Expedited delivery options may be available. Email [email protected] or call customer service at 800-522-2025 and we'll make it happen.




    Share!

    California Residents:
    8pt-triangleWARNING:
    Cancer and Reproductive Harm - www.P65Warnings.ca.gov





    Bi-directional SDI/HDMI with Delay and Frame Sync

    Roland's new video converters address the demand for high-quality, lossless video and audio converters for live/post production as well as installed systems. They include the Roland VC-1-HS (HDMI to SDI), VC-1-SH (SDI to HDMI), and VC-1-DL (Bi-directional SDI/HDMI with audio/video delay and frame sync).

    The VC-1 Video Converter series provides uncompromising picture quality by maintaining the video characteristics of the original signal with rich-blacks and super-whites. There are no interlacing artifacts or other conversion or signal errors sometimes found with other video converters. The VC-1 series also features an on-board re-clocker to compensate for attenuation of SDI signals carried over long distances. The VC-1 series also supports both level A and B 3G-SDI, letting you connect a variety of higher quality SDI sources.

    The VC-1 series is HDCP compliant allowing you to convert or pass-through HDCP signals with the exception of any SDI output. The VC-1-DL additionally enables the HDCP signal to be delayed. Selectable audio embedding and de-embedding lets you route different audio sources to or from video devices. Digital AES/EBU input and output signals are supporting ensuring high-quality audio signals can be maintained through the signal flow.


    • Features

      • HDMI to SDI Conversion
      • SDI to HDMI Conversion
      • Lossless Image Conversion
      • 3G ( Level A&B) /HD/ SD SDI
      • HDCP Support
      • Selectable Channel forEmbedded/De-Embedded Audio
      • Built-in Frame Synchronizer
      • Audio Delay - up to 9 fields (4.5 frames)
      • Video Delay - up to 9 fields (4.5 frames)
      • VC-1 RCS, PC/Mac Control Application

    • Specifications

      • Input
      • SDI Connector
      • BNC type x 1
      • HDMI Connector
      • Type A (19 pins) x 1
      • Analog Audio Connector
      • 1/4" TRS phone type ( balanced ) x 1 pair (L/R)
      • Digital Audio Connector
      • 1/4" TRS phone type ( balanced ) x 1 (Combined use with Analog Audio R ch Connector )
      • Reference Connector
      • BNC type x 1
      • Reference Signal Format
      • Black Burst, Bi-level, Tri-level
      • Reference Impedance
      • 75 ohms

      • Processing
      • Video delay ( 0 to 4.5 frames ) Audio delay ( 0 to 4.5 frames ) Audio embedding Audio de-embedding

      • Output
      • SDI Connector
      • BNC type x 1
      • HDMI Connector
      • Type A (19 pins ) x 1
      • Analog Audio Connector
      • 1/4" TRS phone type ( balanced ) x 1 pair ( L/R)
      • Digital Audio Connector
      • 1/4" TRS phone type (balanced ) x 1 (Combined use with Analog Audio R ch Connector)
