StarTech ST124HD4K 1x4 4K HDMI Splitter

ITEM #: ST-124HD4K MFG #: 124HD4K

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$90.99

Our Price:

$84.82

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    124HD4K - Overview

    The StarTech ST124HD4K 4-port 4K HDMI splitter lets you share four HDMI displays or projectors with an HDMI-enabled audio / video source devices, such as a computer, Blu-ray player or cable TV set-top box.

    With support for Ultra HD (4K) the HDMI splitter ensures astonishing picture quality, four times the resolution of high-definition 1080p at 30 Hz. The 4K splitter is also backward compatible with previous HDMI revisions, supporting 1080p / 720p HDMI video resolution devices. Even if you don't require 4K video today, the ST124HD4K ensures you'll be ready to take advantage of tomorrow's display technology.

    Save time while setting up your splitter with EDID emulation ensuring all of your native settings such as resolution and refresh rate are communicated between your video source and displays. EDID emulation maximizes compatibility with your 4K display, ensuring a convenient plug-and-play installation.

    Constructed of solid aluminum, the HDMI splitter casing is heavy enough to prevent the unit from shifting or sliding around when you move the attached HDMI cables. Plus, the small footprint allows for seamless integration into any digital signage application.

    The StarTech Advantage
    1. Take advantage of 4K (Ultra HD) video with compact HDMI 4K splitter enabling you to handle the latest devices and displays
    2. Ensure your splitter stays where you put it with a solid aluminum housing, unlike lighter plastic splitters that get dragged out of place by attached HDMI cables
    3. Ensure an ideal video output with EDID emulation

    Applications
    Display a 4K HDMI signal on four different HDMI displays
    Use to showcase 4K displays, by outputing the same video source on multiple displays
    Display corporate information or advertising on multiple displays at a shopping center
    Use to display a stock ticker or promotional information at financial institutions
    Display the same information on multiple displays in waiting rooms in healthcare facilities

    • Features:

      • Supports Ultra HD video resolutions up to 4K @ 30Hz
      • Support for 7.1 surround sound audio
      • 4x HDMI outputs
      • Solid aluminum housing
      • Small footprint
      • EDID emulation

    • Specifications:

      • Hardware
      • Audio: Yes
      • Industry Standards: HDMI 1.4
      • Output Signal: HDMI
      • Ports: 4

      • Performance
      • Audio Specifications: 7.1 Surround sound
      • Maximum Digital Resolutions: 4K @ 30 Hz
      • Supported Resolutions: 3840x2160 (4K), 2560x1600, 1920x1200, 1920x1080 (1080p), 1280x720 (720p)
      • Wide Screen Supported: Yes

      • Connector(s)
      • Connector A: 1 - HDMI (19 pin) Female
      • Connector B: 4 - HDMI (19 pin) Female

      • Indicators
      • LED Indicators: 4 - Active port LED, 1 - Power LED

      • Power
      • Input Current: 0.35 A
      • Input Voltage: 100 ~ 240 AC
      • Output Current: 1 A
      • Output Voltage: 5 DC
      • Power Source: AC Adapter Included

      • Environmental
      • Humidity: 5% to 90%
      • Operating Temperature: 0°C to 70°C (32°F to 158°F)
      • Storage Temperature: -10°C to 80°C (14°F to 176°F)

      • Physical Characteristics
      • Color: Black
      • Product Height: 0.6 in [14 mm]
      • Product Length: 5.5 in [139 mm]
      • Product Weight: 9.8 oz [277 g]
      • Product Width: 3.3 in [84 mm]

    • Item Includes:

      • 1 - 4-Port HDMI A/V Splitter
      • 1 - Power Adapter (NA/EU/UK/AUS)
      • 1 - Instruction Manual

    • Warranty:

      • 2 Years

    • GTIN:

      0065030858335
