StarTech USB3SDOCKHDV USB 3.0 Docking Station with HDMI & DVI/VGA

ITEM #: ST-USB3SDOCKHDV MFG #: USB3SDOCKHDV

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$113.99

Our Price:

$106.99

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    USB3SDOCKHDV - Overview

    This StarTech USB3SDOCKHDV USB 3.0 dock combines three USB 3.0 ports, headphone and microphone audio connectors, and a Gigabit Ethernet RJ45 port, into a single docking station for maximum productivity.

    Display Adaptability
    Offering flexible dual video combinations right out-of-the-box, this universal laptop docking station features HDMI, DVI and VGA external monitor outputs. Each video output supports HD video resolutions (2048x1152 max) and HD video playback for an ideal solution to expanding your notebook's video capability.

    Available display combinations:
    HDMI + VGA
    HDMI + DVI

    Integrated USB Hub
    The built-in USB hub features three USB 3.0 ports for connecting extra peripherals such as external hard drives or a wired mouse, as if they are connected directly to your laptop.

    Direct Ethernet Connectivity
    The integrated RJ45 Ethernet port supports speeds of 10/100/1000 Mbps, giving you an instant connection to a wired network.

    StarTech laptop docking stations can be used for cost savings and faster deployment with just a single cable. This USB 3.0 Docking Station is backed by a competitive 3-year warranty and free lifetime Technical Support.

    • Features:

      • Save time by connecting multiple peripherals through a single cable
      • Increase available screen space with dual independent HD video outputs
      • Expand connectivity with additional USB 3.0 ports
      • Connect dual monitors using either HDMI + DVI-D, or HDMI + VGA combinations
      • Connect devices with 3 USB 3.0 ports
      • Connect to wired networks with the built-in 10/100/1000 Mbps compatible RJ45 Ethernet port
      • TAA compliant GSA schedule purchases

    • Specifications:

      • Hardware
      • 4K Support: No
      • Bus Type: USB 3.0
      • Chipset ID: DisplayLink - DL-3900
      • Genesys Logic - GL3520
      • Realtek - RTL8211E
      • Displays Supported: 2
      • Fast-Charge Port(s): No
      • Industry Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, USB 3.0

        Performance
      • Audio Specifications: The HDMI port supports audio output
      • Auto MDIX: Yes
      • Compatible Networks: 10/100/1000 Mbps
      • Full Duplex Support: Yes
      • Maximum Analog Resolutions: 2048x1152 (VGA)
      • Maximum Data Transfer Rate: 5 Gbps (USB 3.0) / 2 Gbps (Ethernet; Full-Duplex)
      • Maximum Digital Resolutions: 1920x1200 (DVI-D) / 1920x1080 (HDMI)
      • Lower resolutions are also supported.
      • Type and Rate: USB 3.0 - 5 Gbit/s

        Connector(s)
      • Connector Type(s): 1 - DVI-D (25 pin) Female, 1 - HDMI (19 pin) Female, 1 - RJ-45 Female, 1 - USB Type-B (9 pin) USB 3.0 Female, 1 - VGA (15 pin, High Density D-Sub) Female, 2 - 3.5 mm Mini-Jack (3 Position) Female, 3 - USB Type-A (9 pin) USB 3.0 Female

        Software
      • OS Compatibility: Windows® XP SP3 (32-bit), Vista, 7, 8, 8.1, 10
      • macOS 10.6 - 10.12, 10.14 - 10.15

        Special Notes / Requirements
      • System and Cable Requirements: Available AC electrical outlet
      • HDMI (and either DVI-D or VGA if dual display is desired) enabled display device(s) e.g. monitor, projector, HTDV, etc. with cables
      • USB 3.0 enabled computer system with available USB 3.0 port

        Power
      • Center Tip Polarity: Positive
      • Input Current: 0.9 A
      • Input Voltage: 100 - 240 AC
      • Output Current: 4 A
      • Output Voltage: 5 DC
      • Plug Type: B
      • Power Consumption (In Watts): 20
      • Power Source: AC Adapter Included

        Environmental
      • Humidity: 0~90% RH
      • Operating Temperature: 0°C to 40°C (32°F to 104°F)
      • Storage Temperature: -10°C to 60°C (14°F to 140°F)

        Physical Characteristics
      • Cable Length: 3 ft [0.9 m]
      • Color: Black
      • Material: Plastic
      • Product Height: 1.7 in [4.4 cm]
      • Product Length: 12 in [30.4 cm]
      • Product Width: 7 in [17.8 cm]
      • Weight of Product: 10.4 oz [295 g]

        Packaging Information
      • Package Height: 2.6 in [66 mm]
      • Package Length: 11.7 in [29.6 cm]
      • Package Width: 7.7 in [19.5 cm]
      • Shipping (Package) Weight: 31 oz [878 g]

    • Item Includes:

      • 1x Docking Station
      • 1x 0.9m USB 3.0 Cable
      • 1x Universal Power Adapter (NA/EU/UK/AU)
      • 1x Installation CD
      • 1x Instruction Manual

    • Warranty:

      • 3 Years

    • GTIN:

      0065030851299
