Teradek 10-2102 Bolt 4K 750 12G-SDI/HDMI Wireless RX

ITEM #: TER-10-2102 MFG #: 10-2102

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Teradek
Free Shipping with $49 Minimum Order
Availability: Sold Out
iAvailability Description Popup
    Report Lower PriceLarge Quantity Quote

    10-2102 - Overview

    The Teradek 10-2102 Bolt 4K is a revolution in wireless video featuring the best reliability and image quality in the industry.

    Note: The 10-2102 is the Bolt 4K Receiver Only!

    Real-Time 4K Wireless Video
    Transmit uncompressed video in 1080p and 2160p at 60FPS with less than 1ms of delay. Up to 750 ft. of range.

    True HDR Color
    Bolt 4K is compliant with the HLG, PQ, and HDR-10 standards, making it an invaluable tool on set for HDR workflows.

    Rock-Solid Reliability
    Bolt 4K features 8x the wireless performance of previous Bolt generations, ensuring video is delivered in even the toughest of RF environments.

    Universal Compatibility
    Each transmitter can send video to up to 6 receivers. Compatible with any model in the Bolt 4K line.

    Inputs/Outputs
    2x 12G-SDI, 1x HDMI 2.0

    Battery Plates
    Optional Gold or V-Mount battery plate with pass-through power available.

    Camera Metadata
    Send start / stop flags, timecode, and other ancillary data over the wireless link. On the receiver side, upload and apply custom 3D LUTs to monitor each take with the look you're after.

    Bolt App for iOS
    Remotely pair units, configure settings, and utilize all of Bolt 4K's features from any iOS smartphone or tablet. The Bolt App uses Bolt 4K's integrated Bluetooth to give you all of its settings in the palm of your hand

    • Features:

      • Includes: 1 RX
      • Video: Up to 4K60FPS
      • Range: 750 ft.
      • Outputs: 12G-SDI, HDMI 2.0
      • Multicast: Up to 6 RXs
      • Compatibility: Bolt 4K 750, Bolt 4K 1500


    • Specifications:

      • Video
      • Video Outputs: 2 x 12G-SDI SMPTE 2082-1 standard / 75 O (accepts 12G-SDI, 6G-SDI, or 3G-SDI), 1 x HDMI Type-A receptacle accepts
        HDMI 2.0 or HDMI 1.4)
      • SDI Ancillary Data Support: Supports transmitting metadata, timecode, and start/stop flags from most camera manufacturers.
      • Color Sampling: SDI: YCbCr 4:2:2, 10-bit/ HDMI: RGB 4:4:4, 8-bit
      • Input Cross Conversion: Yes, HDMI to SDI
      • Delay Tx To Rx: <0.001sec

        Supported Resolutions
      • 4Kp23.98/24/25/29.97/30/50/59.94/60
      • 1080p23.98/24/25/29.97/30/50/59.94/60
      • 1080psf23.98/24/25/29.97/30
      • 1080i50/59.94/60
      • 720p50/59.94/60
      • 480p50 576p59.94/60
      • 480i(NTSC)/576i(PAL)

        Video Processing
      • Video Compression: Visually Lossless
      • Color Correction: 17x17x17 3D LUT (supports 10-bit color)

        Audio Processing
      • Audio Format: 48kHz 24-bit PCM

        Outputs
      • Audio Output: Embedded SDI/HDMI Audio Output (2 Channel)

        Physical
      • Dimensions: 112 x 139 x 27 mm
      • Weight: 432g (15.2 Oz)
      • Construction: Milled Aluminum(Chassis) and regulation-compliant PCB
      • Mountability: Multiple mounting options with 1/4"x20 and M3 holes

        Interfaces
      • Configuration Interfaces: OSD with Menu, Joystick Navigation
      • Switches: On/Off Switch
      • USB Interface Functionality: Upgrade via Micro-USB

        Network
      • Antennas: 5 External 2 dBi antennas (included) or optional Array Panel Antenna
      • Wireless: Non-DFS Frequencies: 5.190 ~ 5.230 GHz and 5.755 ~ 5.795 GHz DFS Frequencies: 5.270 ~ 5.670 GHz
      • Channel Bandwidth: 13x 40MHz wide channels
      • Rf Channel Selection: Auto, Manual Manual available for non-DFS Channels
      • Encryption: AES-256, RSA-1024 key exchange
      • Rf Power: 17 dbm EIRP (one external 2dBi antenna) (<51mW transmit power)
      • Range: Up to 750 ft, line of sight
      • Unicast Multicast: Can connect one Transmitter to up to 6 Receivers
      • Noise Rejection: Can coexist with WiFi and 5GHz cordless phones, Can operate up to 6 sets in same location

        Power
      • Power Input: 2-Pin Circular locking Connector 6-28 VDC
      • Battery: None, optional Gold or V mount battery plate
      • Nominal Power Consumption: 18 Watts


    • Item Includes:

      • 1x Bolt 750 12G-SDI/HDMI Wireless RX
      • 1x Bit 118 2pin Conn. to PowerTap - 18in Cable
      • 1x USB Male Type A (Full) - USB Male Type B (Micro) -3ft Cable
      • 1x Ultra Thin HDMI Male Type A (Full) - HDMI Male Type A (Full) 18in Cable
      • 1x SDI 12G BNC to BNC Cable Length: 18in / 46cm
      • 1x Large Universal Box
      • 1x Foam Bolt 4K RX
      • 1x Small Insert for Large Universal Box Bolt 4K
      • 1x Sticker for Universal Box - Bolt
      • 1x PSU 2pin Conn. to 30W AC Adapter (Int) - 6ft Cable
      • 5x Antenna 2dBi WIFI 2.4/5.8GHz (Small Antenna)
      • 1x Teradek Standard Terms and Conditions
      • 1x Insert - Product Register
      • 1x Quickstart Guide - Bolt 4K 750/1500
      • 1x Insert - Bolt 4K A/C Adapter Requirements


    • GTIN:

      0818264025505
