VigilLink VLSP-14H20 1x4 HDMI 2.0 18Gbps 4K2K Distribution Amplifier - HDMI 2.0b / HDCP 2.2 Compliant

ITEM #: VGL-VLSP-14H20 MFG #: VLSP-14H20

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
VigilLink
Free Shipping with $49 Minimum Order

Our Price:

$142.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
  • Special Order Item: non-cancelable, non-returnable, non-refundable.
Report Lower PriceLarge Quantity Quote

VLSP-14H20 - Overview

The VigilLink VLSP-14H20 1x4 HDMI 18Gbps Splitter is an advanced solution for splitting a single HDMI signal into 4 HDMI displays. It provides high-performance audio and video output through HDMI cables up to 4K2K@60Hz 4:4:4 and can receive and transmit up to 18Gbps of bandwidth with no data loss. (Supporting the latest features, you can be assured of reliable and high-quality HDMI distribution.)

  • Features:

    • HDMI 2.0b, HDCP 2.2 compliant
    • Supports video format up to 4K2K@60Hz with 8-bit RGB/YCbCr 4:4:4/YCBCR 4:2:2
    • Supports 3D frame sequential video format up to 1080p@60
    • Supports 3D frame sequential video format up to 4K2K@30Hz
    • Supports high-resolution VESA mode video format up to QSXGA@60Hz
    • Supports LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio
    • Supports smart EDID control
    • Compact design for an easy and flexible installation
    • Related Pro


  • Specifications:

    • Video Bandwidth: 600MHz/18Gbps
    • Input Ports: 1x HDMI Type A (19-pin female)
    • Output Ports: 4x HDMI Type A (19-pin female)
    • ESD Protection: Human Body Model: ±8kV (Air-gap discharge) & ±4kV (Contact discharge)
    • Power Supply: 5V/1A DC (US/EU standards, CE/FCC/UL certified)
    • Dimensions: 2.48" x 6.42" x 0.63" (63mm x 163mm x 16mm)
    • Weight: 1.12lbs (509g)
    • Chassis Material: Metal
    • Silkscreen Color: Black
    • Power Consumption: 2W
    • Operating Temperature: 32°F - 104°F (0°C - 40°C)
    • Storage Temperature: -4°F - 140°F (-20°C - 60°C)
    • Relative Humidity: 20% - 90% RH (No condensation)


  • Item Includes:

    • 1x 1x4 HDMI 18Gbps Splitter
    • 1x 5V/1A DC Power Adapter
    • 1x User Manual


  • Warranty:

    • 6 Years
