Allen Avionics MADI-ISO-B MADI / AES10 Audio Isolation Transformer

ITEM #: AAV-MADI-ISO-B MFG #: MADI-ISO-B

Primary Image
Free Shipping with $49 Minimum Order

Our Price:

$169.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


    MADI-ISO-B - Overview

    MADI / AES10 Digital Audio Isolator
    Allen Avionics MADI-ISO-B is a Digital Audio Isolation Transformer that eliminates hum or noise present in Multichannel Audio Digital Interface (MADI) or AES10. This is caused by differences in ground potential up to 20 Volts or due to induced currents in long cable runs. Such interference results in degradation of bit timing in high speed digital signals and causes higher Bit Error Rates suffered from the Cliff Effect. This compact, standalone unit provide the much needed electrical isolation between the Input and Output.

    • Features:

      • Eliminates hum and noise in Digital Audio Channels
      • Isolated Signal Path helps in protecting equipment from Ground Voltages
      • Supports all MADI / AES10-2008 Digital Audio Formats
      • Data Rate up to 250 Mb/s Greater than 60 dB of Ground Loop Isolation
      • Passive Device - No power required
      • Small Cylindrical Package with Gold BNC Connectors for better response
      • 75 Ohms Balanced with Insertion Loss less than 0.25 dB
      • Greater than 20 dB Return Loss
      • 2 kV flash tested

    • Item Includes:

      • 1x Allen Avionics MADI-ISO-B MADI / AES10 Audio Isolation Transformer
