Apantac OG-3G-Mux-12G-SET-1 openGear SDI Bundle with OG-3G-Mux-12G-MB & OG-3G-Mux-12G-RM - 2 Slots in openGear Frame

OG-3G-MUX-12G-SET-1 - Overview

• Features:

  • OGX/3.0 card-based form factor
  • Dashboard control enabled
  • Supports 4 x 3G input (quad link) input, 2SI or Square Division
  • Supports 1 x 12G SDI video Output
  • Analog audio output
  • Passes HDR from input to output
  • Optional 12G SDI fiber output via SFP
  • Low power consumption - less than 15W


• Specifications:

  • Description: Quadlink 3G SDI(2SI/SQD) Mux to 1x 12G SDI output
  • Inputs: 4 x 3G SDI
  • Outputs: 1 x 12G SDI, optional fiber output
  • Audio: Stereo Analog audio output
  • Control: Dashboard


• Item Includes:

  • 1x Apantac OG-3G-Mux-12G-SET-1 openGear Bundle with OG-3G-Mux-12G-MB & OG-3G-Mux-12G-RM - 2 Slots in openGear Frame


• Warranty:

  • 5 year limited
