AtlasIED BB-168AECDT BlueBridge 16 Input x 8 Output Networkable DSP Device with Acoustic Echo Cancellation & Dante

ITEM #: ATL-BB-168AECDT MFG #: BB-168AECDT

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$7,206.99

Our Price:

$5,767.99

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    BB-168AECDT - Overview

    The BlueBridge® BB-168AECDT networkable DSP devices with Acoustic Echo Cancellation and Dante™ is a powerful and flexible tool offering mission critical solutions to successfully satisfy your customers' teleconferencing and video conferencing needs. Engineered to strict standards with the highest quality internal components, BlueBridge® DSP solutions provide pure clean analog and digital audio, Ethernet connectivity for cost effective TCP/IP control and open architecture with Drag and Drop programmability. AtlasIED offers the widest range of open architecture DSP platform I/O configurations of any manufacturer in the industry, all configured using the same software.

    The BlueBridge® AEC model with the Dante™ digital audio network chipset offers up to 16 channels of self-configuring, true plug-and-play digital audio over an Ethernet network providing the highest quality audio over existing network infrastructure.

    • Features:

      • Wide-Band Acoustic Echo Cancellation
      • Dante™ Ethernet Based Digital Audio
      • True Plug-and-Play Digital Audio Networking
      • 16x8 I/O Configuration
      • Open Architecture Programmability
      • High Quality THAT® Corporation Mic Preamps
      • TCP/IP Third Party Control Capability
      • Four Logic Inputs & Outputs
      • 48kHz, 40 Bit Floating DSP Engine
      • Remote Control Using Optional Wall Plates
      • Output Peak & Signal Indicator LEDs
      • Safety Listed to UL60065

    • Specifications:

      • Input Type: Mic or Line, GUI Selectable
      • Power Requirement: 90-240VAC (50-60Hz)
      • Input Gain: -40 to +15dB in 0.25 dB steps
      • Phantom Power: 48V, GUI Enabled
      • Output Type: Line
      • Output Impedance: 50Ω
      • RAID: 40-Bit Floating Point
      • Sample Rate: 48kHz
      • Analog Converters: High Performance 24-Bit
      • Width: 19" (483mm)
      • Height: 1.75" (44mm)
      • Depth: 9" (229mm)

    • Item Includes:

      • 1x Atlas BB-168AECDT BlueBridge 16 Input x 8 Output Networkable DSP Device with Acoustic Echo Cancellation

    • GTIN:

      0612079190102
