Atlona AT-HDR-EX-100CEA-KIT 4K HDR HDMI Over 100 M HDBaseT Transmitter/Receiver with Ethernet Control PoE & Return Audio

ITEM #: ATNO-ATEX100CEAK MFG #: AT-HDR-EX-100CEA-KIT

free ship

Our Price:

$1,332.00

Availability: In Stock
iAvailability Description Popup


    AT-HDR-EX-100CEA-KIT - Overview

    The Atlona AT-HDR-EX-100CEA-KIT is an HDBaseT transmitter/receiver kit for high dynamic range (HDR) formats.

    The kit is HDCP 2.2 compliant and supports 4K/UHD video @ 60 Hz with 4:4:4 chroma sampling, as well as HDMI data rates up to 18 Gbps. The HDR-EX-100CEA-KIT provides transmission of HDMI, Ethernet pass-through, and bidirectional IR and RS-232 control signals up to 330 feet (100 meters) over CAT6a/7 cable. This extender kit features visually lossless compression with no latency to enable HDR and 4K/60 4:4:4 video signal extension over HDBaseT. For additional integration convenience, the transmitter remotely powers the receiver through Power over Ethernet (PoE). The HDR-EX-100CEA-KIT can transmit digital audio from a television back to an AV receiver, via a dedicated audio pathway.

    The HDR-EX-100CEA-KIT is ideal for residential and commercial applications with the latest as well as emerging 4K/UHD and HDR sources and displays. It is compatible with all video resolutions, audio formats, and color space formats supported in the HDMI 2.0b specification, plus the ability to pass metadata for HDR content. The HDR-EX100CEA-KIT includes Atlona's award-winning 10 year limited product warranty and customer support services, so that integrators can specify, purchase, and install with confidence.


    Applications:

  • Residential installations The HDR-EX-100CEA-KIT is designed for AV systems with the latest UHD and HDR sources such as Ultra HD Blu-ray players, plus compatible televisions and projectors.
  • TV showrooms The HDR-EX-100CEA-KIT can be used for reliable content transmission to televisions, to properly demonstrate the quality and appeal of 4K and HDR programming.
  • Professional AV applications Atlona 4K HDR products are ideal for full-motion, highly detailed 4K graphics presentations for visualization, 3D renderings, simulations, and more.
    • Features:

      • 4K/UHD capability @ 60 Hz with 4:4:4 chroma sampling, plus support for HDR formats
      • HDCP 2.2 compliant
      • HDBaseTTM extender kit for HDMI®, Ethernet, power, and control up to 330 feet (100 meters)
      • Receiver powered by transmitter via PoE (Power over Ethernet)
      • Extends RS-232, IR, Ethernet, and CEC control signals over HDBaseT
      • Delivers return audio from a TV via dedicated audio pathway
      • HDBaseT link status testing

    • Specifications:

      • Transmitter
      • HDMI IN: 1x Type A, 19-pin female
      • HDMI OUT: n/a
      • USB: 1x Mini Type A, 5-pin female
      • RS-232/IR: 1x 5-pin captive screw
      • HDBaseT: 1x RJ45
      • LAN: 1x RJ45
      • OPTICAL IN: n/a
      • OPTICAL OUT: 1x TOSLINK
      • DC 48V: 1x 2-pin captive screw
      • TEST Button: 1x Momentary, Tact-type
      • TEST LED: 1x Tri-color (green, amber, red)
      • POWER LED: 1x LED, green
      • LINK LED: 1x LED, amber

        Receiver
      • HDMI IN: n/a
      • HDMI OUT: 1x Type A, 19-pin female
      • USB: 1x Mini Type A, 5-pin female
      • RS-232/IR: 1x 6-pin captive screw
      • HDBaseT: 1x RJ45
      • LAN: 1x RJ45
      • OPTICAL IN: 1x TOSLINK
      • OPTICAL OUT: n/a
      • DC 48V: n/a
      • TEST Button: n/a
      • TEST LED: n/a
      • POWER LED: 1x LED, green
      • LINK LED: 1x LED, amber

        Video
      • UHD/HD/SD: [email protected]/25/30/50/60Hz, [email protected]/25/30/50/60Hz, 2048x1080p, [email protected]/24/25/29.97/30/50/59.94/60Hz, [email protected]/59.94/60Hz, [email protected]/59.94/60Hz, 576p, 576i, 480p, 480i
      • VESA: 2560x2048, 2560x1600, 2048x1536, 1920x1200, 1680x1050, 1600x1200, 1600x900, 1440x900, 1400x1050, 1366x768, 1360x768, 1280x1024, 1280x800 1280x768, 1152x768, 1024x768, 800x600, 640x480
      • Color Space: YUV, RGB
      • Chroma Subsampling: 4:4:4, 4:2:2, 4:2:0
      • Color Depth: 8-bit, 10-bit, 12-bit
      • HDR: 4K HDR10 @ 60 Hz and Dolby® Vision™ @ 30 Hz

        Audio
      • Formats: PCM 2Ch, LPCM 5.1, LPCM 7.1, Dolby® Digital, DTS 5.1, Dolby Digital Plus™, Dolby TrueHD, DTS-HD, Master Audio™, Dolby Atmos®, DTS:X®
      • Sample Rate: 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
      • Bit Rate: 24-bit (max.)

        Resolution/Distance
      • 4K/UHD:
        CAT5e: 295ft (90m)
        CAT6/CAT6a/CAT7: 330ft (100m)
      • 1080p:
        CAT5e: 330ft (100m)
        CAT6/CAT6a/CAT7: 330ft (100m)

        Signal
      • Maximum TMDS Clock: 600MHz
      • HDMI: 2.0
      • CEC: Yes
      • HDCP: 2.2

        Temperature
      • Operating: 32°F - 122°F (0°C - 50°C)
      • Storage: -4°F - 140°F (-20°C - 60°C)
      • Humidity (RH): 20% - 90%, non-condensing

        Power - Transmitter/Receiver
      • Consumption: 5.25W/7.55W
      • Input: 100 - 240V AC, 50/60Hz
      • Supply: 48V DC, 0.83 A

        Physical
      • Transmitter Dimensions (HxWxD): 1.02" x 5.74" x 3.74" (26mm x 146mm x 95mm)
      • Receiver Dimensions (HxWxD): 1.02" x 5.74" x 3.81" (26mm x 146mm x 97mm)
      • Transmitter Weight: 0.886lbs (0.402kg)
      • Receiver Weight: 0.873lbs (0.396kg)

    • Item Includes:

      • 1x AT-HDR-EX-100CEA-TX
      • 1x AT-HDR-EX-100CEA-RX
      • 4x Mounting brackets
      • 8x Mounting screws
      • 1x 48V DC power supply
      • 1x IR emitter
      • 1x 5-pin captive screw connector
      • 1x 6-pin captive screw connector
      • 1x Installation Guide

    • GTIN:

      0846352005795
