Blustream CEX4K-KIT HDMI over Coax Extender Set - 4K HDMI Signals up to 100m over a single 75 Ohm Coaxial Cable

CEX4K-KIT - Overview

• Features:

  • Extends 4K HDMI signals up to a distances of 100m over a single 75 ohm coaxial cable
  • Supports up to 4K 60Hz 4:4:4 UHD video*
  • Supports Bi-directional IR from input and output locations
  • Supports PCM 2.0 channel audio
  • Supplied with Blustream IR receiver and emitter
  • Smart EDID management
  • HDCP 2.2 compliant
    *Note: HDR 10/12 bit formats not supported. Requires local power at both Transmitter and Receiver devices.


• Specifications:

  • CEX4K Transmitter
  • Video Input Connectors: 1 x HDMI Type A
  • Video Output Connectors: 1 x BNC connector
  • IR Input ports: 1 x 3.5mm stereo jack
  • IR Output ports: 1 x 3.5mm mono jack
  • Product upgrade: 1 x Micro USB, female
  • Dimensions (Casing - W x D x H): 72.7mm x 88.8mm x 24mm
  • Dimensions Including Connections (W x D x H): 72.7mm x 106.8mm x 24mm

    CEX4K Receiver
  • Video Input Connectors: 1 x BNC connector
  • Video Output Connectors: 1 x HDMI Type A
  • IR Input ports: 1 x 3.5mm stereo jack
  • IR Output ports: 1 x 3.5mm mono jack
  • Product upgrade: 1 x Micro USB, female
  • Dimensions (Casing - W x D x H): 72.7mm x 88.8mm x 24mm
  • Dimensions Including Connections (W x D x H): 72.7mm x 106.8mm x 24mm


• Item Includes:

  • 1x CEX4K-TX
  • 1x CEX4K-RX
  • 2x 5V/1.2A DC power supply
  • 1x IRE1 emitter
  • 1x IRR receiver
  • 2x Mounting brackets
  • 2x F-type to BNC adaptor
  • 1x Quick reference guide
