Datavideo SE-500HD 1080p 4 Input HDMI Video Switcher with Built-in Audio Mixer

ITEM #: DV-SE-500HD MFG #: SE-500HD

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$1,199.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    SE-500HD - Overview

    The Datavideo SE-500HD a multi-format live event AV switcher with scaling on every input, built-in audio mixer, and exceptional 4:4:4 10-bit 1080p video quality. Its portable & compact design with easy-to-use professional features makes it ideal for breakout rooms, corporate events, and any live event production. Four scaled HDMI inputs and two HDMI outputs allow users to mix and match video resolutions and connect a variety of video sources that include laptops, tablets, and cameras without the need for video converters.

    Don't let the SE-500HD fool you with its compact size and affordable price. It is loaded with features such as Lumakey for graphic overlays, split screen for side by side views of the presenters, and PIP (picture-in-picture) for PowerPoint presentations. Plug in microphones and other audio sources directly into the SE-500HD and use the built-in audio mixer to simplify your workflow and get professional sound. Dedicated buttons make it user friendly and easy for anyone to operate it like a pro. Professional features, compact all-in-one design and affordable price point makes the SE-500HD ideal for any live presentation.

    • Features:

      • 4 Channel HD/SD Digital Video Switcher
      • Supports up to Full HD 1080p
      • 10-bit processing
      • Video Input: 4x HDMI
      • Video Output: 2x HDMI (1x Multiview | 1x Program)
      • Audio Input: 1x Stereo RCA | 2x Microphone
      • Audio Output: 1x Stereo RCA | 1x Stereo headphone mini Jack
      • Audio Mixer: 2x Mic | 1x Stereo RCA | 1x internal Digital embedded
      • Audio LED Meter
      • Transitions: Wipe, Mix & Cut
      • Keyer: Lumakey
      • Picture-in-picture and split functions
      • Tally Output

    • Specifications:

      • Video Standard: Full HD & SD
      • Video Format: 1080p 50/59.94/60Hz; 1080i 50/59.94/60Hz; 720p 50/59.94/60Hz; 576i 50Hz; 480i 59.94Hz
      • Video Processing HDMI: YUV 4:4:4 10 bit, RGB: 4:4:4
      • Video Input: 4x HDMI
      • Computer Graphic Interface: 4 via HDMI
      • Video output: 2x HDMI (1 is MV, 1 is PGM)
      • Built-in Multi-view monitoring out: HDMI
      • Audio input: 1x Stereo RCA (L/R); 2x Mono Microphone; De-embedded Digital Audio (2 CH)
      • Audio output: 1x Stereo RCA (L/R); 1x Stereo headphone (Mini Jack with volume control); Embedded Digital Audio (2 CH)
      • Embedded audio support: embedded 2-CH digital/analogue audio
      • Effects: FTB, Cut, Wipe with border
      • Sync / Reference In/Out: Built-in Genlock (internal)
      • Tally Output: 1x D-sub 15pin, dual color
      • Chassis: Unibody
      • Power: DC 12V 29W
      • Accessory: CB-60/61/62 (30/50/100m)

    • Item Includes:

      • 1x SE-500HD product
      • 1x AD Switch DC 12V with AC Cord
      • 1x Thank You Card

    • GTIN:

      0672255007198
