Ensemble Designs BrightEye 83-H HDMI to 3G / HD / SD SDI Converter with HDCP
  • Ensemble Designs BrightEye 83-H HDMI to 3G / HD / SD SDI Converter with HDCP
  • Ensemble Designs BrightEye 83-H HDMI to 3G / HD / SD SDI Converter with HDCP
  • Ensemble Designs BrightEye 83-H HDMI to 3G / HD / SD SDI Converter with HDCP
  • Ensemble Designs BrightEye 83-H HDMI to 3G / HD / SD SDI Converter with HDCP

Questions? Ask a Markertek Expert:
800-522-2025 Email

Ensemble Designs BrightEye 83-H HDMI to 3G / HD / SD SDI Converter with HDCP

Manufacturer: Ensemble Designs

Item #: ENDE-BE83-H   •   MFG #: BRIGHTEYE 83-H



List Price:$600.00
Our Price:$570.00

free ship


Availability:
Extended Lead Time. Email, Chat or Call Us for more details.
i
This item is currently subject to an extended manufacturer’s lead time. Please email, chat or call us at 800-522-2025 for more details.



    California Residents:
    8pt-triangleWARNING:
    Cancer and Reproductive Harm - www.P65Warnings.ca.gov





    Convert HDMI to 3G/HD/SD SDI with the BrightEye 83-H. The output format follows the input, faithfully preserving the input's resolution and frame rate. Perfect for GoPro, Replay and other video cameras and sources with an HDMI output, BrightEye 83-H presents the serial digital video signal on two BNC outputs.

    Signal monitoring and control is provided through the included BrightEye Mac and BrightEye PC software.

    BrightEye 83 and BrightEye 83-F convert HDMI to 3G, HD or SD SDI. These units are convenient for broadcast video cameras and other sources with an HDMI output. BrightEye 83 and 83-F pass embedded audio and support all 8 audio channels on the HDMI input. BrightEye 83 converts HDMI to standard definition video signals and 3 Gb/s and 1.5 Gb/s high definition signals. BrightEye 83-F presents both electrical and optical serial digital outputs The optical output can drive single mode fiber to a distance of 20 kilometers. With an optical launch power attenuator, multi-mode fiber can also be used. Signal monitoring is provided on the front panel of the unit, and through the included BrightEye Mac and BrightEye PC software. In compliance with the licensing restrictions on HDCP encrypted material, BrightEye 83 and 83-F cannot convert encrypted signals to SDI form.


    • Features

      • Guaranteed to work perfectly with your GoPro camera
      • HDMI to SDI (3G/HD/SD formats supported)
      • Use with Cameras and Other Sources that have an HDMI Output
      • Passes Embedded Audio
      • Supports HDCP Encrypted Content

    • Specifications

      • Input
      • Number One, supports HDCP encrypted content
      • Type HDMI 1.3
      • Format Supports HDMI signals which map to the video standards listed below

      • SDI Standards Supported
      • 1080i (SMPTE 274M -4,5,6) 50, 59.94 or 60 Hz
      • 720p (SMPTE 296M -1,2,3) 50,59.94 or 60 Hz
      • 1080p (SMPTE 274M -9,10,11) 23.98, 24, 25 Hz
      • 1080sF (RP211 -14,15,16) 23.98, 24, 25 Hz
      • 1080p (SMPTE 424M, 425M), 50, 59.94, 60, Level A
      • 525i, 625i (SMPTE 259M)

      • Serial Digital Output
      • Number Two, BNC
      • Signal Type Follows input
      • Impedance 75 Ω
      • Return Loss >15 dB to 1.485 GHz >10 dB to 2.97 GHz
      • Output DC None (AC coupled)

      • General Specifications
      • Size 5.625" W x 0.8" H x 5.5" D(143 mm x 20 mm x 140 mm) including connectors
      • Power 12 volts, 5 watts (100-230 VAC modular power supply)
      • Temperature Range 0 to 40° C ambient (all specs met)
      • Relative Humidity 0 to 95° non-condensing

    • Warranty

      • 5 years
