StarTech ST128HD20 8-Port 4K 60Hz HDMI Splitter

ITEM #: ST-ST128HD20 MFG #: ST128HD20

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$197.99

Our Price:

$197.43

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    ST128HD20 - Overview

    This 4K HDMI splitter lets you connect your HDMI video source to eight HDMI displays, with support for Ultra HD resolutions and HDR (High Dynamic Range) as well as 7.1 surround sound audio.

    Supports true 4K at 60Hz
    This StarTech ST128HD20 8-port 4K 60Hz HDMI splitter offers full support for your HDMI 2.0 equipment, including true 4K resolution at 60Hz. For smoother video and color transitions, the splitter offers 4:4:4 chroma subsampling, meaning every pixel gets its own unique color. Support for HDMI 2.0 devices means this splitter can transmit bandwidth up to 18Gbps, making it the ideal solution for high-resolution tasks requiring the highest color detail.

    Note: In order to support 4K 60Hz coming through the splitter, each device in the chain must support HDCP 2.2.

    Widely compatible
    The splitter supports HDCP 2.2 and is backward compatible with 4K 30Hz and 1080p displays. This ensures that it will work with lower resolution displays such as TVs or projectors around your site or in your digital signage application.

    Easy installation and setup
    The 4K HDMI splitter offers easy plug-and-play installation with no additional software or drivers required. The splitter passes EDID between your video source and the display attached to port 1, ensuring native settings such as resolution and refresh rate are configured automatically.

    The ST128HD20 is backed by a 2-year StarTech warranty.

    Applications:
    Output and split your 4K 60Hz HDMI signal to eight different HDMI displays
    Distribute 4K 60Hz video to computer monitors that require the highest quality of image detail, such as in control centers or video production studios
    Share corporate information or advertising on multiple displays with digital signage
    Display the same information on multiple displays in the waiting rooms of healthcare or educational institutions

    • Features:

      • Offers HDMI 2.0 technology which can support 4K 60Hz HDR
      • 7.1 surround sound audio
      • Supports 4:4:4 chroma subsampling even at 4K 60Hz with bandwidth up to 18Gbps
      • Backwards compatible with 4K 30Hz and 1080p displays
      • Tidy, professional installation with mounting hardware included

    • Specifications:

      • Hardware
      • Audio: Yes
      • AV Input: HDMI
      • AV Output: HDMI
      • Cabling: HDMI
      • Industry Standards: HDMI 2.0
      • HDCP 2.2
      • Ports: 9

        Performance
      • Audio Specifications: 7.1 surround sound
      • Maximum Digital Resolutions: 3840x2160 (4K) @ 60Hz
      • Supported Resolutions: 2560x1600
      • 1920x1200
      • 1920x1080 (1080p)
      • 1280x720 (720p)
      • Wide Screen Supported: Yes

        Connector(S)
      • Connector A: 1 - HDMI (19 pin) Female
      • Connector B: 8 - HDMI (19 pin) Female

        Special Notes / Requirements
      • Note: This video splitter is not compatible with the AMD Radeon RX460 graphics card
      • Connect the HDMI display with the lowest resolution and refresh rate capability to output #1
      • If HDCP 1.4 display is connected to port #1 the whole system defaults to HDCP 1.4.

        LED Indicators
      • 1 - power LED
      • 1 - input LED
      • 8 - output LEDs

        Power
      • Center Tip Polarity: Positive
      • Input Current: 0.6A
      • Input Voltage: 100 - 240AC
      • Output Current: 3A
      • Output Voltage: 5DC
      • Plug Type: M
      • Power Consumption (In Watts): 15W

        Environmental
      • Humidity (RH): 10 to 85% (non-condensing)
      • Operating Temperature: 32° to 113°F (0° to +45°C)
      • Storage Temperature: 14° to 158°F (-10° to 70°C)

        Physical Characteristics
      • Product Height: 1" [2.6cm]
      • Product Length: 10.2" [25.8cm]
      • Product Width: 4.3" [11cm]
      • Weight of Product: 26.9oz [762g]

        Packaging Information
      • Package Height: 2.8" [70mm]
      • Package Length: 12.8" [32.5cm]
      • Package Width: 10.2" [26cm]
      • Shipping (Package) Weight: 2.7Lb [1.2kg]

    • Item Includes:

      • 1x HDMI splitter
      • 1x Universal power adapter (NA/JP, UK, EU, ANZ)
      • 1x Set of mounting brackets

    • GTIN:

      0065030876049
