    NSP12GIO - Overview

    A fast and easy way to video over IP and the perfect solution for broadcast quality productions without the complex set-up.

    The VIZRT Spark IO 12G-SDI not only offers a fast and easy way to video over IP but now supports up to 4K 60p 12G-SDI video inputs and outputs. This simple solution means the VIZRT Spark family of products supports the whole spectrum of video production. The Spark IO 12G-SDI is the perfect solution for broadcast quality productions without the complex set-up.

    VIZRT Spark Plus IO 12G-SDI offers broadcast media production professionals a quick and easy solution to use up to UHD 60p video in IP based media production workflows. With VIZRT Spark™ Plus IO 12G-SDI, anyone can easily connect 12G-SDI cameras or devices, convert the video signal to high bandwidth NDI®, and then share it with any compatible system, device, or application anywhere on the network. The same Spark Plus IO 12G-SDI takes signals from anywhere on the network and converts the video for sending to UHD screens, monitors, projectors, or video walls.

    Your workflow, your choice
    VIZRT Spark™ Plus video converters are the fastest, easiest, and best way to video over IP. Ultra-portable enclosures with resolutions up to UHD 60p, the groundbreaking benefits of NDI®, and a host of tools and capabilities makes VIZRT Spark Plus video converters the right choice for all sorts of video applications.

    Compatible With Any NDI® Workflow
    Share video over IP with any compatible system, device, or application that supports NDI, including VIZRT solutions and products from third-party manufacturers and developers.

    NDI® Transfer Modes
    Transmit video to your network using your choice of supported NDI transfer modes, to include unicast and multicast UDP with forward error correction (FEC), and unicast TCP.

    NDI® Input and Output
    Acquire video from connected devices such as cameras and deliver as IP to networks with NDI or provide IP with NDI from networks to destinations such as displays.

    Send and receive video with networks via Ethernet and be instantly available as NDI® sources and endpoints for any compatible system, device, or application.

    Portable and Mountable
    Carry VIZRT Spark™ Plus video converters with you wherever you go, or optionally mount to a compatible camera or support using the industry-standard threaded screw mount.

    Present high-quality audio with support for analog and embedded digital sources.

    Program and Preview Tally
    Receive tally notification from compatible NDI® devices via a physical LED when video output from any VIZRT Spark™ Plus product is visible on Program and/or Preview.

    NDI® Virtual Input
    Designate your video input source in popular desktop video applications like Google Hangouts, GoToMeeting, Skype, Skype for Business, WebEx, Zoom, and more using the NDI® Virtual Input tool.

    * NDI Virtual Input included with VIZRT NDI Tools download at no charge.

    Web-Based Interface
    Monitor video, manage login credentials, access recording controls, and configure audio, video, and network settings from any supported Web browser on any compatible networked device.

    Multicast Mode
    Permit multiple destinations as an option to receive your video source without individual point-to-point connections to conserve network bandwidth.

    Network Identification
    Easily identify devices on your network with the ability to apply custom device and channel names.

    Network Visibility
    Access devices connected to other networks via IP address and make them visible within your production environment using NDI® Access Manager.

    • Features:

      • Compatible With Any NDI Workflow
      • NDI Transfer Modes
      • NDI Input and Output
      • Connectivity
      • Portable and Mountable
      • Audio
      • Program and Preview Tally
    • Specifications:

      • Video Input: 1 x 12G-SDI
      • Video Output: 1 x 12G-SDI
      • Audio Input: 1 x 12G-SDI embedded audio input 1 x 3.5 mm analog stereo line level
      • Audio Output: 1 x 12G-SDI embedded audio output 1 x 3.5 mm analog stereo line level
      • Decoding: NDI
      • Networking: 1 Gigabit Ethernet
      • Interface: Web-based user interface for configuration and monitoring
      • Tally: Tally support via NDI
      • Formats: 2160p: 59.94, 50, 29.97, 25 1080p: 59.94, 50, 29.97, 25 720p: 59.94, 50, 25
      • Power: Power over Ethernet or external power adaptor DC 5V~18V power supply
      • Physical:
        Portable enclosure with threaded screw camera mount
        4.33 x 3.7 x 1.1 in (110 x 95 x 28 mm)
        0.66 lbs (.30 kg) Subject to change without notice.
