tvONE 1T-SX-654 4x1 4K60 HDMI 2.0 Switcher with HDCP 2.2
  • tvONE 1T-SX-654 4x1 4K60 HDMI 2.0 Switcher with HDCP 2.2
  • tvONE 1T-SX-654 4x1 4K60 HDMI 2.0 Switcher with HDCP 2.2

Questions? Ask a Markertek Expert:
800-522-2025 Email

tvONE 1T-SX-654 4x1 4K60 HDMI 2.0 Switcher with HDCP 2.2

Manufacturer: tvONE

Item #: TV1-1T-SX-654   •   MFG #: 1T-SX-654




Our Price:$360.00

free ship


Availability: Direct Ship From Manufacturer
i
Item ships directly from the manufacturer and is subject to manufacturer availability. We will contact you with expected availability. You can also email [email protected], chat or call customer service (800)-522-2025 for expedited delivery options.




    Share!

    California Residents:
    8pt-triangleWARNING:
    Cancer and Reproductive Harm - www.P65Warnings.ca.gov





    The 1T-SX-654 is an ultra-thin auto switcher with four HDMI video inputs and one HDMI output with resolution support up to [email protected] 4:4:4 HDR. Control options include auto-switch mode, which automatically switches to an HDMI input as soon as a new source is connected, or control via the front panel source button, RS-232 or IR (remote control included).

    Audio functionality includes multi-channel support, de-embeded digital stereo audio to provide an analog output, or an audio return channel (ARC) for transmitting audio back to the HDMI input from the connected display.


    • Features

      • Switch any of the four HDMI inputs to a single HDMI output
      • Supports video resolution up to [email protected] 4:4:4 HDR
      • 18Gbps high bandwidth
      • HDMI 2.0 and HDCP 2.2 compliant
      • Audio return channel (ARC) support
      • Ultra-thin (12mm) design for easy install
      • Controllable via RS-232 and IR
      • Supports Consumer Electronics Control (CEC)
      • Advanced EDID management

    • Specifications

      • Video Input
      • Input: (4) HDMI 2.0
      • HDCP compliance: HDCP 2.2
      • HDMI Input Resolution: Up to [email protected] 4:4:4
      • HDCP Version: 2.2

        Video Output
      • Output: (1) HDMI 2.0
      • HDMI Output Resolution: Up to [email protected] 4:4:4
      • HDCP Version: 2.2

        Audio
      • Output: (1) PCM via 3.5mm mini stereo audio jack
      • Audio Format: PCM
      • Audio Output Impedance: 70 Ohms
      • Frequency Response: 20Hz to 20kHz, ±3dB

        Control
      • Control: Front panel button
      • IR IN: via 3.5mm mini jack
      • RS232: via 3.5mm mini jack

        General
      • Bandwidth: 18Gbps
      • Operation Temperature: 14°F - +131°F (-10°C - +55°)
      • Storage Temperature: -13°F - +158°F (-25°C - +70°C)
      • Relative Humility: 10% - 90%
      • Power Supply Input: 100V - 240V AC
      • Output: 5V DC 1A
      • Power Consumption: 5W (Max)
      • Dimensions (H x W x D): 7.64" x 0.47" x 3.19" (194mm x 12mm x 81mm)
      • Weight: 0.4 lbs (180g)
