Pliant Technologies CRT-900 CrewCom 900MHz Radio Transceiver

ITEM #: PLI-CRT-900 MFG #: CRT-900

  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
free ship

Our Price:

$2,475.00

Availability: Typically Ships in 3-10 Days
iAvailability Description Popup


    CRT-900 - Overview

    Pliant Technologies CRT-900 900MHz Radio Transceiver that supports up to 6 Radio Packs. Power is provided over a CrewNet copper connection or via an optional 48 VDC power supply (sold separately).

    NOTE: This 900 MHz product ONLY available in North America.

    • Features:

      • Supports up to 6 Radio Packs
      • Supports a selectable Normal or High Density mode of operation
      • CrewNet connections (etherCon or duplex LC Single Mode Fiber) with network status indicators
      • Status indicators for data RX/TX, operation mode, and error
      • CrewNet RT Loop connection for connecting up to 8 CrewCom Radio Transceivers
      • Micro USB connection for firmware updates
      • Dual powering options (network power, external 48VDC-sold separately)

    • Specifications:

      • RF Frequency (MHz): 902-928 MHz
      • RF Scheme: FHSS with TDMA
      • Effective Radiated Power: 315mW (+26dBm)
      • Receiver Sensitivity: -100dBm
      • Radio Certification FCCID: HSW-CCT900 and IC: 4492A-CCT900
      • Transmission Range: 650 ft. (200 m) under typical conditions; 1950 ft. (600 m) line of sight (Note: Functional range depends on many variables, including RF signal absorption, reflection, and external interference.)
      • No. of Radio Packs Supported (when RT in Normal Mode): 6
      • No. of Radio Packs Supported (when RT in High Density Mode): 32
      • Number of Antenna Connections per RT: 2
      • Antenna Connector Type: RP-TNC
      • Supplied Antenna: +2dBi Omni-directional (whip)
      • CrewNet In Port (supports 1 connection): (1) RJ-45 for copper; (1) duplex LC for Single Mode Fiber
      • RT Loop Port (1): RJ-45
      • Maximum Line Length: Copper 330 ft. (100 m); Fiber 32,800 ft. (10,000 m)
      • Network Power: CrewNet RJ-45 only
      • External Power: 48VDC Power Supply (Sold Separately)
      • Dimensions without Antennas (inches): 6.30 in. × 7.74 in. × 1.81 in. (16 cm × 19.7 cm × 4.6 cm)
      • Weight: 1.25 lbs (567 g)
      • Operating Environment: -20° to 50° C (-4° to 122° F); 10% to 90% Humidity
      • Maximum Altitude: 9,842 ft. (3,000 m)
      • RoHS: Yes

    • Item Includes:

      • Radio Transceiver, Omni-Directional Antenna (x2), 15 ft. (4.6 m) Cat 5e Cable, USB A to Micro B cable, Mounting Hardware and Bracket (2x), Microphone Stand Adapter, Product Overview Guide, Warranty Extension Registration Card

    • Warranty:

      • 2 Years (2nd Year Requires Registration)
