Roland V-1-4K Video Switcher with ROI Mode - 5 IN/5 OUT HDMI Connectivity for 4K and HD - 4K USB Streaming Output

ITEM #: ROL-V-1-4K MFG #: V-1-4K

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$1,899.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


V-1-4K - Overview

The Roland V-1-4K covers professional video production needs for in-person events, livestreaming, studio productions, and other applications. The all-in-one V-1-4K is compact, easy to carry, and quick to set up, featuring 5-in/5-out HDMI connectivity for both 4K and HD and up to 4K USB streaming output. Its ROI (Region of Interest) mode lets users crop up to four areas from a single 4K source for multiple shots, while built-in audio mixing, PTZ camera control, and remote operation via dedicated apps streamline production. Paired with the Graphics Presenter software, it also enables polished titles and motion graphics, all while delivering 4K60p and HDR processing with the simple, intuitive operation the V-1 series is known for.

The Best Practical Option For Entry-Level 4K Video Production
Inheriting simple operability of V-1 series, V-1-4K is the industry first practical option of 4K video switchers in the entry market with easy-to-use operability. V-1 Series has been defining the entry-level video switcher market since 2004. V-1-4K will take over the role in 4K world.

More Shots, Less Cameras. Streamline Video Production
ROI feature enables having multiple shots by cropping specific areas from a single 4K camera source. It helps to reduce setup time and create more shots on a video production.

True 4K/60P Processing in a Compact Footprint
Best in class specification - 4K/60p processing with HDR support. The all-in-one design enables easy to carry and set up even a small video production space in a venue.

Free Valuable Software Options: Graphics Presenter, VenuSet and full control apps support elevating video production quality from entry-level to professional users.

  • Features:

    • Versatile 4K I/O with Stress-Free Connection
      - All inputs have scaler that enables connection in various video signals format from HD to 4K without format converters.
      - 5 outputs allow system flexibility on system configurations.
      - In addition to PGM, Preview and Multi-view outputs, output channel 3 and 4 can be assigned any output bus and any input signal with 4K to HD down scalers.
      - Up to 4K/60p USB streaming output.
    • Practical Free Software Options
      - V-1-4K supports Graphics Presenter and VenuSet.
      - Graphics Presenter is a Windows based software that allows to create stunning titles and motion graphics with compatible Roland video switchers. The setup is easy, connecting PC and a switcher enables Fill and Key composition.
      - VenuSet (iPadOS/macOS/Windows) allows a customizable solution that makes it easier to operate the V-1-4K.
    • Efficient Multi-Angle Shots with ROI Feature
      - In "ROl" mode, allowing to create multiple shots cropping from a single 4K video source.
      - This powerful feature elevates a production value without increasing camera count, complexity, or costs.
      - V-1-4K Remote/RCS app helps cropping area setup with intuitive operation.

  • Specifications:

      Video
    • Video Processing: 4:2:2 (Y/Pb/Pr), 8-bit
    • Number of Video Channels: 5 channels
    • Video Input Connectors: HDMI IN 1-5: 5x HDMI type A (HDMI2.0)(HDCP 1.4 2.2 Supported, Multi-format Supported)
    • Video Output Connectors:
      - HDMI OUT 1-4: 4x HDMI type A (HDMI2.0)(HDCP 1.4 2.2 Supported)
      -HDMI OUT 5: 1x HDMI type A (HDMI1.4)(HDCP 1.4 Supported)
      - USB STREAM: 1x USB Type-C (R)(USB2.0/USB3.2 Gen1)
    • USB HOST: 1x USB A type (for USB flash drive)
    • USB STREAM: 1x USB Type-C (R)(for remote control from PC and iPad)
    • LAN CONTROL: 1x RJ45, 100BASE-T (for Remote Control)
    • Input Formats:
      - 720/60p, 59.94p, 50p
      - 1080/59.94i, 50i (The input interlaced video signal is converted to progressive video signal by internal processing.)
      - 1080/60p, 59.94p, 50p, 30p, 29.97p, 25p, 24p, 23.98p
      - 2160/60p, 59.94p, 50p, 30p, 29.97p, 25p, 24p, 23.98p (HDMI IN 1-3 supports YUV420)
      - UXGA (1600x1200/60Hz), WUXGA (1920x1200/60Hz), WQHD (2560x1440/60Hz)(Conforms to CEA-861-G, VESA CVT. HDMI IN 5 support Roland FILL+KEY signal. Color Gamut and Dynamic Range are the same as the system format.)

      Power
    • Power Supply: AC adpater
    • Current Draw: 4A
    • Power Consumption: 52W

      Audio
    • Sample Rate: 24 bits, 48kHz
    • Number of Audio Channels: 14 channels
    • Audio Formats:
      - USB STREAM (input/output): Linear PCM, 16 bits, 48kHz, 2 ch
      - HDMI IN: Linear PCM, 24 bits, 48kHz, 2 ch
      - HDMI OUT: Linear PCM, 24 bits, 48kHz, 2 ch
    • Channel Effects: High pass filter, Noise gate, Compressor, 4-Band equalizer, Delay, Auto mixing
    • Master Effects: 4-Band equalizer, Compressor/Limiter, 15-Band GEQ, Delay
    • Other Effects: Output fade, Test tone output
    • Audio Input Level: AUDIO IN 1, 2: +4dBu (Maximum: +24dBu)
    • Audio Input Impedance: AUDIO IN 1, 2: 16kΩ
    • Audio Output Level:
      - AUDIO OUT 1, 2: -10dBu (Maximum: +10dBu)
      - PHONES: 92mW + 92mW (32Ω)
    • Audio Output Impedance:
      - AUDIO OUT 1, 2: 1kΩ
      - PHONES: 10Ω

      Audio Input Connectors
    • Analog: AUDIO IN 1-2: 2x XLR type
    • Digital:
      - USB STREAM: 1x USB Type-C (R)
      - HDMI IN 1-5: 5x HDMI type A
      - PHONES: 5x 3.5mm Stereo miniature phone type

      Audio Output Connectors
    • Analog:
      - AUDIO OUT 1-2: 2x RCA phono type (R/L)
      - PHONES: 5x 3.5mm Stereo miniature phone type
    • Digital:
      - USB STREAM: 1x USB Type-C (R)
      - HDMI OUT 1-5: 5x HDMI type A

      Physical
    • Dimensions (WxDxH): 13" x 6.6" x 3.15" (330mm x 164mm x 79mm)
    • Weight: 4lbs (1.9kg)
    • Operation Temperature: 32°F - 104°F (0°C - 40°C)

  • Item Includes:

    • 1x AC Adapter
    • 1x Power Cord

  • Warranty:

    • 3 Year Limited Warranty
