KanexPro EXT-4kHD70M 4K60Hz HDMI Extender over Cat6 - up to 230 Feet/70M


  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
free ship

Our Price:


Availability: Typically Ships in 3-10 Days
iAvailability Description Popup

    EXT-4KHD70M - Overview

    The KanexPro EXT-4KHD70M HDMI extender includes a transmitter and receiver units, allows for HDMI signals to be transmitted up to 70 meters at 4K resolution using a Cat6/6a/7 network cable. This is perfect for outdoor advertising, monitor systems, home entertainment and conference room solutions.

    Ideal for use in digital signage applications, healthcare AV, control rooms, educational facilities, airports, commanding centers and home theater.

    Note: Use a CAT5e/6 cable with low impedance STP(Shielded twisted pair) is recommended with proper grounding for excellent transmission of AV signals.

    • Features:

      • Zero Latency
      • Supports transmission distance up to 230ft. (70m)
      • Supports HDR(YUV 4:4:4)
      • Supports UHD 4K (4K x 2K @ 60Hz)
      • IR bi-directional Pass through 20-60KHz (kits included)
      • HDCP 2.2 & EDID support for multiple displays
      • Simple set up with zero configuration
      • Compact design for flexible installations
      • Support ARC S/PDIF digital audio de-embedded outputs
    • Specifications:

      • Power Supply
      • Voltage/Current: DC5V-12V
      • Power Consumption: TX: <4W RX: <4W

        HDMI Performance
      • HDMI Compliance: HDMI 2.0
      • HDCP Compliance: HDMI 2.2
      • HDMI Supported Resolutions: [email protected], [email protected], [email protected],[email protected], [email protected]/60Hz, [email protected]/60Hz, [email protected]/60Hz, [email protected]/25/30/50/60Hz, [email protected]/25Hz, 1280x960, 1280x800, 1280x768, 1680x1050, 1360x768, 1366x768, 1600x900, 1024x768, 800x600
      • Supported Audio Formats: 100-240V , 50/60Hz, 0.3A

        Transmission Distance
      • Cat6, Cat6A, or Cat7: up to 70M at 4K resolution

        Operating Enviroment
      • Working Temperature: -20~60°C
      • Storage Temperature: -30~70°C
      • Humidity (No Humidity): -0~90%RH

        Physical Properties
      • Dimentions: 106.0(L) x 99.0(W) x 26.2(H)mm
      • Material: Aluminum
      • Color: Black
      • Weight: TX-210g RX-210g
    • Item Includes:

      • 1x KanexPro EXT-4kHD70M 4K60Hz HDMI Extender over Cat6 - up to 230 Feet/70M
    • Warranty:

      • Backed by KanexPro's 3 Year limited
    • GTIN:
