Fiberplex SFP-SC24XC-3131-B Singlemode Optical SFP (OC24) 1310nm Tranceiver- 20Km

ITEM #: SFP-SC24XC-3131B MFG #: SFP-SC24XC-3131-B

free ship

Our Price:


Availability: In Stock
iAvailability Description Popup

    SFP-SC24XC-3131-B - Overview

    The FiberPlex Technologies Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). The SFP transceivers are high performance, cost effective modules supporting a host of data rates and distances. They are RoHS compliant and lead-free. These optical modules are designed for digital data applications and are not recommended for digital video applications due to SMPTE encoding that may cause pathological signal errors. For video applications see our line of Video Optimized SFP Modules.

    • Features:

      • Duplex LC connector
      • Hot-pluggable SFP footprint
      • RoHS compliant and Lead Free
      • Metal enclosure for lower EMI
      • Single +3.3V power supply
      • Low power dissipation <800mW
      • SFP MSA SFF-8074i Compliant
    • Specifications:

      • TX/RX: FP/PIN
      • Data Rate: 1.25 Gbps
      • Sonet/SDH/IEEE: OC24/Fibre Channel/GbE
      • Fiber Type: Singlemode
      • Wavelengths (nm): 1310
      • Transmitter Power Min (dBm): -9
      • Transmitter Power Max (dBm): -3
      • Receiver Sensitivity (dBm): -25
      • TX Jitter (Jtxp-p): 200 ps
      • Max Distance at Max Data Rate: 20k
