Vanco HDBT4K50 HDBaseT 4K/60Hz HDR HDMI Extender - 164ft./50m - 1080p 230ft./70m - HDCP 2.2 Bi-directional IR PoC

ITEM #: VCO-HDBT4K50 MFG #: HDBT4K50

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$871.99

Our Price:

$726.99

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    HDBT4K50 - Overview

    The Vanco HDBT4K50 HDBaseT 4K@60Hz, 4:4:4 Chroma, HDR Extender with Bi-directional IR, and Power over Cable (PoC) extends 4K/60Hz, 4:4:4 with HDR along with audio, at a distance of up to 164ft/50m over a single Cat5e/6 cable. Also able to pass 1080p/60Hz up to 230ft/70m. Power over Cable (PoC) Technology transmits power over Cat5e/6, allowing either the Transmitter or Receiver to be powered without the use of a power supply for an easy installation. No EDID or EQ adjustments are necessary as the units automatically adjust for compatibility and gain. In addition, bi-directional IR pass-through allows for source and/or display control. For extending full 4K resolution with up to 60Hz, 4:4:4 chroma subsampling, and HDR, the HDBT4K50 is a great plug and play solution for connecting the latest components!

    The HDBT4K50 includes two units: transmitting unit (HDBT4K50-TX) and receiving unit (HDBT4K50-RX). The transmitting unit is used to capture the HDMI input with IR signals and carries the signals via one cost effective Cat5e/6 cable. The receiving unit is responsible for equalizing the transmitted HDMI signal and reconstructing IR signals. The HDBT4K50 offers the most convenient solution for 4K extension over a single Cat5e/6 with Power over Cable, and is the perfect solution for any application.

    • Features:

      • Features the latest HDBaseT Technology, optimized for whole-home or commercial distribution of high definition signals at much greater distances of standard HDMI cables
      • Transmission Range: Extends 4K@60Hz, 4:4:4 with HDR up to 164ft/50m over a single Cat5e/6 cable and 1080p@60Hz up to 230ft/70m
      • Features Power over Cable technology (PoC) which transmits power over Cat5e/6, allowing for either Transmitter or Receiver to be powered without the use of a power supply
      • Virtually Lossless Compression retains high end audio and video quality
      • Bi-directional IR control
      • Features Auto EDID and EQ Management for plug and play installation
      • HDR Compatible
      • HDCP 2.2 compliant and backward compatible to previous versions
      • CEC Support
      • Slim and compact design
      • Power Supply: DC 12V, 2A
      • Dimensions: 5.75" W x .7" H x 3.7" D

    • Specifications:

      • Transmitter Input: HDMI IN
      • Transmitter Output: HDBaseT OUT
      • Receiver Input: HDBaseT IN
      • Receiver Output: HDMI OUT
      • Transmitter Control Ports: IR IN IR OUT
      • Receiver Control Ports: IR IN, IR OUT
      • Transmission Mode & Distance: HDBaseT; 1080P ≤ 70m; 4Kx2K w/HDR ≤ 50m
      • Resolution: Up to 4Kx2K@60Hz 4:4:4 with HDR
      • HDMI Standard: 6HDMI 2.0 & HDCP 2.2
      • Power Consumption: 20W (max)
      • Temperature: -10°C ~ 50°C
      • Humidity: 0%~90 %
      • Power Supply: Input: 100VAC~240VAC, 50/60Hz; Output: 24VDC 1.25A
      • Dimensions: 146.2mm x 94mm x 17.9 mm

    • Item Includes:

      • 1x HDBT4K50 (TX & RX)
      • 1x IR Transmitter (IR TX)
      • 1x IR Receiver (IR RX)
      • 1x Mounting Hardware
      • 1x DC 12V Power Supply
      • 1x Product Manual
