AViPAS AV-2000G Full HD 20x NDI/HX & HDMI PTZ Camera with PoE - Black

ITEM #: AV-2000G MFG #: AV-2000G

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$945.00

Our Price:

$895.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    AV-2000G - Overview

    The AviPas AV-2000G is a 20X NDI|Hx & HDMI PTZ camera with PoE supported. It features 1/2.8" 2.4MP high quality CMOS sensor to capture video images in 1080p up to 60fps. The camera features simultanous HDMI and NDI|Hx/IP (shared same RJ45 port) outputs, and with NDI|Hx that allows you streaming video and audio with low -latency on your network. The camera is suitable for various A/V applications such as video conferencing, Esports, medical training, educational fields and houses of worship.

    The 20x optical zoom, F1.5~F3.0 lens with advanced 2D/3D noise reduction & a minimum illumination of 0.1 Lux, AV-2000G can provide more clarity and vivid image even in low-light conditions. The camera supports PoE (Power over Ethernet) which delivers power to camera , control signal and video out over a single Cat5/6 cable, this makes simplified the installation and cost effective. The camera also supports H.264/H.265 compression and IP straming in multiple protocols: such as RTSP, RTMP/RTMPS, SRT & HTTP. The camera also has a 3.5mm audio Line -in with AAC audio encoding for NDI|Hx/ IP streaming out. AV-2020G can be controlled by included IR remote control, LAN over RJ45 port (IP control/config) or RS232 via serial commands (RS232 compatible with RS485/shared with RS485).

    • Features:

      • 20x optical zoom, 2x Digital zoom
      • 1/2.8" CMOS Sensor, 2.4MP effective pixel
      • Full HD 1920x1080p up to 60 fps
      • Lens: f=4.9mm~98mm, F1.5~3.0
      • 0.1 Lux minimum illumination @ F1.5
      • Field of View: 60 degree
      • Pan: -170° ~ +170° Tilt: -90° ~ +90°
      • 2D&3D digital noise reduction, SNR>50dB
      • Horizontal/Vertical image flip
      • WDR (Wide Dynamic range) and BLC (Backlight compensation) supported
      • Image freeze supported
      • Anti-Flicker: OFF/50Hz/60Hz
      • H.264/H.265 Video streaming encoding (default H.264)
      • HDMI, IP/NDI|Hx simultaneous outputs
      • 3.5mm Audio Line-in with AAC encoding for IP/NDI|Hx out
      • Multiple IP streaming protocol: RTSP, RTMP/RTMPS, SRT, HTTP, TCP/IP, DHCP, Onvif, NTP
      • Network speed: 1000M
      • Preset positions: 128 via RS232(RS485) or IP; 10 via IR remote control
      • Control options: IR remote, LAN (IP config/ONVIF/NDI) and RS232 serial control
      • Control Protocol: VISCA, VISCA Over IP, Pelco-D/Pelco-P, OnviF & NDI
      • RS232 input and output for easier daisy chain, RS232 input compatible and shared with RS485
      • PoE supported: IEEE 802.3af Standard
      • Standard wall and ceiling mountings
      • Tripod mountable (1/4"-20 female on the bottom)

    • Specifications:

      • Camera Specifications
      • Image Sensor: 1/2.8" CMOS sensor, effective pixel: 2.4MP
      • Shutter Speed: 1/30s ~ 1/10000s (auto/manual)
      • Minimum Illumination: 0.1Lux @ (F1.5, AGC on)
      • Gain: 0db-30db
      • White Balance: Manual, Auto, ATW (auto tracking white balance) Indoor, Outdoor, One Push mode
      • Image Flip: Horizontal /Vertical image flip
      • Image freeze supported

        Video Format
      • HDMI: 1920x1080P 60/59.94/50/30/29.97/25/24/23.98, 1920x1080I 60/59.94/50, 1280x720P 60/59.94/50/30/29.97/25

        RJ45
      • 1920x1080@3~30 / 1280x720@3~30 / 1024x576 @3~30 (Main stream), 1280x720@3~30 / 1024x576@3~30 / 640x360 @3~30 (Sub stream)

        Video Outputs
      • 1x HDMI
      • 1x LAN (RJ45)

        Audio Inout/Output
      • 1x 3.5mm Line-in audio jack female
      • Embedded audio for IP/NDI|Hx streaming only

        Control interface
      • 1x RS232 input (8pin Mini DIN female, compatible and shared with RS485)
      • 1x RS232 loop output (8pin Mini DIN female)
      • 1x LAN (RJ45)

        IP Specifications
      • Network speed: 1000M
      • Video encode: H.264 (default)/H.265
      • Video bit rate: 1024Kbps~16384Kbps

        Lens Specifications
      • Zoom Ratio: 20x (Optical), 2x (Digital)
      • Focal Length 4.9 ~ 98mm; Apeture: F1.5~ F3.0
      • Horizontal Angle of View: 60° ~ 3.23°
      • Focus: Auto /Manual
      • Preset positions: 128 via RS232(RS485) serial or IP; 10 via IR remote control
      • Rotation angle: Pan: ±170°; Tilt Rotation: -90°~+90°
      • Rotation Speed: Pan: 0°~120°/s; Tilt: 0°~80°/s

        General Specifications
      • Power Requirements: DC 12V/ PoE (IEEE 802.3af)
      • Power Consumption: 10W
      • Operating Temperature: 20°F~80°F
      • Storage Temperature: 20°F~95°F
      • Dimensions: 6.6" x 6.6" x 7.1"
      • Net Weight: 3.1 LB

    • Item Includes:

      • 1x AV-2000G
      • 1x AC power adapter
      • 1x Power cord
      • 1x RS232 cable(8-pin Mini DIN Male to DB-9 Female)
      • 1x IR Remote control
      • 1x User manual

    • Warranty:

      • 2 year conditional

    • GTIN:

      0858738005718
